Regular price $9,899.90 //
/

The all-new Levo delivers the unbelievable power to ride more trails through an unequaled combination of ride quality, usable power, and ride anywhere range. It’s the distillation, application, and amplification of a 40-year obsession with creating the world’s best riding mountain bikes. Since its introduction, Levo has set the bar every other e-MTB aims for, and the new Levo raises that bar again.

It starts with our Turbo Full Power 2.2 motor and Turbo Connect Unit (TCU), which provide Levo with a smooth and seamless amplification of your efforts—4x you power that lets you choose where to ride, and when you want to do it. Levo also shatters limitations when it comes to range, amplifying your effort for up to five hours of trail time. Now you can ride farther, and explore more, than ever before. And the optimized chassis boasts 150mm of custom-tuned rear suspension and adjustable geometry that delivers a stable and natural ride like no other. Because at the end of the day, it’s the ride that matters. Believe it.

The Turbo Levo pairs our all-new M5 alloy chassis and the smoothest and most powerful motor on the market with the most value-packed drivetrain, suspension, and brake components available. The result is a bike that puts plenty of high-dollar e-MTBs to shame.



  • Levo’s fully integrated Turbo Full Power 2.2 motor, 500Wh battery, and Turbo Connect Unit deliver category-leading 90 Nm of torque and 565 watts of power for up to five hours of ride time, empowering you to ride farther and faster than ever before.
  • The Levo’s Turbo Connect Unit (or “TCU”) is more than an “On-Off” button—it’s the brains of the bike. The TCU shows your battery level and power-assist mode. It also communicates, via ANT+/Bluetooth®, with our optional handlebar display to display even more information about your day’s ride.
  • A dedicated mixed-wheel size design with a 27.5” wheel in the back and 29” up front delivers a nimble ride that carves circles around other full-power e-MTBs. A generous cockpit centers you on the bike, optimizing traction and corner control. The low bottom bracket, slack headtube angle and reduced fork offset keep things stable in the rough.
  • Levo offers two distinct geometry settings, allowing you to easily dial-in its performance for any riding style and any terrain. Bottom bracket height can be fine-tuned up or down by 7mm.
  • Levo’s 150mm of rear travel is supple on small bumps, devours square-edged hits without a twitch, eats massive G-outs for breakfast, yet still offers amazing pedal response and delivers your power to the ground with total efficiency.
  • The Levo’s S-Sizing is based on what matters—rider size and style, not inseam. Six sizes, all with similar headtube lengths and standover, allow you to choose the size that best suits your individual style. Smaller S-Size numbers are going to be nimble and more flickable, while bigger S-Sizes deliver more stability and a roomier ride.
      Frame
      Specialized M5 premium alloy, BB height adjust, S-Sizing, internal cable routing, 150mm travel, 148mm spacing
      Rear Shock
      RockShox Deluxe Select R, rebound adjust, S1: 52.5x210mm, S2-S6: 55x210mm
      Fork
      RockShox 35 Silver, 35mm stanchion, Turnkey damper, S1: 150mm travel, S2-S6: 160mm travel
      Stem
      Alloy Trail Stem, 35mm bar bore
      Handlebars
      Alloy, 35mm diameter, 780mm width, 8-degree backsweep, 6-degree upsweep
      Tape
      Specialized Trail Grips
      Front Brake
      SRAM Guide RE, S1-S3: 200mm, S4-S6: 220mm
      Rear Brake
      SRAM Guide RE, 200mm
      Rear Derailleur
      SRAM SX Eagle, 12-speed
      Shift Levers
      SRAM SL SX Eagle, 12-speed
      Cassette
      SRAM NX Eagle PG-1230, 12-speed, 11-50t
      Crankset
      Praxis forged M30, custom offset, 160mm
      Chain
      SRAM NX Eagle, 12-speed
      Chainrings
      SRAM X-Sync Eagle, 104 BCD, 32T, steel
      Rims
      Specialized 29, hookless alloy, 30mm inner width, tubeless ready
      Front Hub
      Alloy, sealed cartridge bearings, 15x110mm thru-axle, 32h
      Rear Hub
      Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
      Spokes
      DT Swiss Industry
      Front Tire
      Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.6"
      Inner Tubes
      Standard, Presta Valve
      Rear Tire
      Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6"
      Saddle
      Body Geometry Bridge Saddle, steel rails
      SeatPost
      TranzX dropper, 34.9mm, S1: 100mm, S2: 125mm, S3: 150mm. S4-S5: 170mm, S6- 200mm
      Seat Binder
      Alloy, 38.6mm
      Motor
      Specialized Turbo Full Power System 2.2 Motor
      UI/Remote
      Specialized TCU, 10-LED State of charge, 3-LED Ride Mode display, ANT+/Bluetooth®, w/Handlebar remote
      Battery
      Specialized M3-500, Integrated battery, 500Wh
      Charger
      Custom charger, 42V4A w/ Rosenberger plug
      Wiring Harness
      Custom Specialized wiring harness
      Size S1 S2 S3 S4 S5 S6
      BB Drop 25 27 27 27 27 27
      BB Height 352 350 350 350 350 350
      Bike Standover Height 752 776 783 787 788 790
      Chainstay Length 442 442 442 442 442 442
      Crank Length 160mm 160mm 160mm 160mm 160mm 160mm
      Fork Length (full) 557 567 567 567 567 567
      Fork Rake/Offset 44 44 44 44 44 44
      Front Center 738 760 784 814 843 878
      Handlebar Width 780mm 780mm 780mm 780mm 780mm 780mm
      Headtube Angle 64.5 64.5 64.5 64.5 64.5 64.5
      Headtube Length 105 105 115 125 135 145
      Max Seatpost Insertion 210 220 240 255 275 295
      Min Seatpost Insertion 80 80 80 80 80 80
      Reach 412 432 452 477 502 532
      Saddle Width 155mm 155mm 143mm 143mm 143mm 143mm
      Seat Tube Angle 78 77.2 76.7 76.2 76.2 76.2
      Seat Tube Length 380 390 405 425 445 465
      Seatpost Length 100mm 125mm 150mm 170mm 170mm 200mm
      Stack 605 617 626 635 644 653
      Stem Length 40mm 40mm 50mm 50mm 50mm 50mm
      Trail 130 130 130 130 130 130
      Wheelbase 1179 1200 1225 1255 1284 1318
      Turbo Levo Comp Size Guide NZ
