One Forty 400 2026
One Forty 400 2026

One Forty 400 2026

Regular price$3,399.00
/
Tax included.

The ONE-FORTY 400 brings an unheard of level of climbing and descending performance into a high-value package built around our test and award-winning aluminium frame. It's got exactly the same ground-breaking geometry as its more expensive brethren, just paired with kit that delivers the performance you need, without the price tag. Dropper posts on all models, a wide-range 11-speed Shimano drivetrain and no-nonsense suspension from Marzocchi get the job done without fuss.

The test and award-winning ONE-FORTY is the ultimate trail bike, made for the toughest trails in the world. It’s the pinnacle of modern trail riding, with a super-steep 80° seat angle, low front end and bottom bracket allow it to clear the most technical climbs, while longer reach figures across all sizes and a well-balanced 65° head angle mean it’s still more than capable of ripping any descent. With our AGILOMETER sizing system, riders can run a longer or shorter reach frame independently of their height, with suspension that becomes more progressive as you size up to better cope with heavier/harder riders. We’ve focused on weight reduction and rolling speed too, for improved efficiency. All bikes come with long travel dropper posts, WIRE PORT cable routing and a reliable threaded bottom bracket plus carbon frames have on-board tool storage and Fidlock magnetic bottle cages.

Frame Size XShort Short Mid Long XLong
Tyre Sizes 29" 29" 29" 29" 29"
ST seat tube [mm] 400 410 425 445 470
TT top tube [mm] 532 559 586 618 649
CS chain stay length [mm] 437.5 437.5 437.5 437.5 437.5
HTA head tube angle [°] 65 65 65 65 65
STA seat tube angle [°] 80 80 80 80 80
BD bottom bracket drop [mm] 35 35 35 35 35
HT head tube [mm] 95 95 95 105 120
FL fork length [mm] 557 557 557 557 557
R reach [mm] 426 453 480 509 535
S stack [mm] 607 607 607 616 629
WB wheel base [mm] 1177 1204 1232 1265 1298
SH stand over height [mm] 730 735 738 735 730
FRAME SIZE BODY HEIGHT
S < 173 cm
M 167 - 183 cm
L 177 - 190 cm
XL > 187 cm
