Forget the numbers. Mute the speculation. Let the other guys invent cute alternatives for "cross country." Steer clear of pigeon holes and limiting beliefs. Strap on your blinders and go get lost. Then decide what the SB120 means to you. And you alone.
Definition ready.
TRAVEL 120MM (4.7")
MATERIAL C/SERIES
FORK ROCK SHOX PIKE ULTIMATE 140MM
SHOCK ROCK SHOX SUPER DELUXE ULTIMATE
WHEELSET DT M1900
REAR DER SRAM EAGLE 90 T-TYPE
SHIFT SRAM EAGLE 90 T-TYPE
CRANK SRAM EAGLE 90 T-TYPE 32T 170MM
BB SRAM DUB BSA 73
CASSETTE SRAM GX EAGLE T-TYPE 10-52
CHAIN SRAM GX EAGLE T-TYPE FLATTOP
BRAKES SRAM CODE R
ROTOR F/R SRAM CENTERLINE 200/SRAM CENTERLINE 180
POST FOX TRANSFER 31.6MM / XS: 125MM, SM: 150MM, MD: 175MM, LG-XXL: 200MM
TIRE (F) MAXXIS MINION DHF 2.5 EXO
TIRE (R) MAXXIS AGGRESSOR 2.3 EXO
HEADSET CANE CREEK 40 INTEGRATED
BAR BURGTEC RIDE WIDE ALLOY ENDURO 35X780MM
STEM BURGTEC ENDURO MK3 35X50MM
GRIPS ODI ELITE PRO
SADDLE SILVERADO CUSTOM
MATERIAL C/SERIES
FORK ROCK SHOX PIKE ULTIMATE 140MM
SHOCK ROCK SHOX SUPER DELUXE ULTIMATE
WHEELSET DT M1900
REAR DER SRAM EAGLE 90 T-TYPE
SHIFT SRAM EAGLE 90 T-TYPE
CRANK SRAM EAGLE 90 T-TYPE 32T 170MM
BB SRAM DUB BSA 73
CASSETTE SRAM GX EAGLE T-TYPE 10-52
CHAIN SRAM GX EAGLE T-TYPE FLATTOP
BRAKES SRAM CODE R
ROTOR F/R SRAM CENTERLINE 200/SRAM CENTERLINE 180
POST FOX TRANSFER 31.6MM / XS: 125MM, SM: 150MM, MD: 175MM, LG-XXL: 200MM
TIRE (F) MAXXIS MINION DHF 2.5 EXO
TIRE (R) MAXXIS AGGRESSOR 2.3 EXO
HEADSET CANE CREEK 40 INTEGRATED
BAR BURGTEC RIDE WIDE ALLOY ENDURO 35X780MM
STEM BURGTEC ENDURO MK3 35X50MM
GRIPS ODI ELITE PRO
SADDLE SILVERADO CUSTOM
| XS | SM | MD | LG | XL | 2XL | ||
| A | SEAT TUBE LENGTH | 13.6 | 14.4 | 15.7 | 17.3 | 18.5 | 19.1 |
| B | EFFECTIVE TOPTUBE LENGTH | 21.3 | 22.5 | 23.8 | 24.6 | 25.7 | 26.5 |
| C | HEADTUBE ANGLE | 66.2 | 66.2 | 66.2 | 66.2 | 66.2 | 66.2 |
| D | EFF. SEAT TUBE ANGLE | 76.1 | 76.2 | 76.2 | 76.2 | 76.2 | 76.2 |
| E | ACTUAL SEAT TUBE ANGLE | 70.8 | 71.2 | 71.6 | 72.0 | 72.4 | 72.9 |
| F | CHAINSTAY LENGTH | 17 | 17.1 | 17.2 | 17.3 | 17.4 | 17.4 |
| G | WHEELBASE | 44.3 | 45.7 | 47.0 | 48.0 | 49.3 | 50.3 |
| H | ESTIMATED BB HEIGHT | 13.3 | 13.3 | 13.3 | 13.3 | 13.3 | 13.3 |
| I | STANDOVER | 27.9 | 28.0 | 28.2 | 28.4 | 28.5 | 28.6 |
| J | HEADTUBE LENGTH | 3.6 | 3.9 | 4.1 | 4.5 | 4.9 | 5.8 |
| K | FORK AXLE TO CROWN | 21.7 | 21.7 | 21.7 | 21.7 | 21.7 | 21.7 |
| L | FORK OFFSET | 1.7 | 1.7 | 1.7 | 1.7 | 1.7 | 1.7 |
| M | STACK | 23.9 | 24.1 | 24.3 | 24.7 | 25.1 | 25.9 |
| N | REACH | 15.4 | 16.6 | 17.8 | 18.6 | 19.6 | 20.1 |
| O | FRONT CENTER | 27.2 | 28.5 | 29.8 | 30.7 | 31.9 | 32.8 |
| P | VERTICAL FORK TRAVEL | 5.0 | 5.0 | 5.0 | 5.0 | 5.0 | 5.0 |
| XS | 4'10-5'5"/ 145-160CM |
| SM | 5'1"-5'7"/155-170CM |
| MD | 5'5"-5'11"/ 165CM-180CM |
| LG | 5'10"-6'3"/178-191CM |
| XL | 6'1"-6'7"/185-201CM |
| 2XL | 6'5"- 6'11"/195-210CM |
