The ARC is back. Conjuring up all the nostalgia, hoots and hollars from yesteryear. It’s your instant-feedback steed for any trail. Show it your singletrack, pump track and your bikepack route too. It’s got history to live up to and new history to make. And it’s already impatient.
SEE NEW SPEC BELOW (THIS MIGHT CHANGE AS WE SELL OUT OF PARTS SO PLEASE CONTACT BEFORE ORDERING)
MATERIAL TURQ SERIES
FORK FOX FACTORY 34 FIT4/130MM**
WHEELSET DT 350 HUB / RACE FACE ARC RIMS
REAR DER SRAM XX EAGLE AXS TRANSMISSION
SHIFT SRAM AXS POD CONTROLLER
CRANK SRAM XX EAGLE TRANSMISSION 30T 170MM
BB SRAM DUB BSA 73
CASSETTE SRAM XX EAGLE TRANSMISSION 10-52
CHAIN SRAM XX EAGLE TRANSMISSION FLATTOP
BRAKES SRAM G2 RSC
ROTOR F/R SRAM CENTERLINE 180/SRAM CENTERLINE 180
POST FOX TRANSFER FACTORY 31.6MM / SM: 150MM, MD: 175MM, LG-XXL: 200MM
TIRE (F) MAXXIS MINION DHF 2.5 EXO
TIRE (R) MAXXIS AGGRESSOR 2.3 EXO
HEADSET CANE CREEK 110 INTEGRATED
BAR YETI CARBON 35X780MM
STEM BURGTEC ENDURO MK3 CNC 35X50MM
GRIPS ODI ELITE PRO
SADDLE ERGON SM ENDURO SADDLE
**FORK OPTIONS :
- 2025 FOX FACTORY 34 GRIP X/130MM
- 2024 FOX FACTORY 34 GRIP 2/130MM
**WHEEL OPTIONS
- DT EXC 1501 CARBON w/240 DEG HUBS
- DT M1700 WHEELSET
| SM | MD | LG | XL | ||
| A | WHEEL SIZE | 29.0 | 29.0 | 29.0 | 29.0 |
| B | REACH | 16.5 | 17.5 | 18.3 | 19.3 |
| C | EFFECTIVE TOP TUBE LENGTH | 22.7 | 23.8 | 24.6 | 25.7 |
| D | STACK | 24.9 | 25.2 | 25.4 | 25.8 |
| E | HEADTUBE LENGTH | 3.7 | 4.1 | 4.3 | 4.7 |
| F | SEAT TUBE LENGTH | 15.0 | 16.1 | 17.7 | 19.5 |
| G | EFF. SEAT TUBE ANGLE | 76.0 | 76.0 | 76.0 | 76.0 |
| H | HEADTUBE ANGLE | 67.0 | 67.0 | 67.0 | 67.0 |
| I | ESTIMATED BB HEIGHT | 12.2 | 12.2 | 12.2 | 12.2 |
| J | CHAINSTAY LENGTH | 17.0 | 17.0 | 17.0 | 17.0 |
| K | FRONT CENTER | 28.0 | 29.1 | 30.0 | 31.1 |
| L | WHEELBASE | 45.0 | 46.1 | 47.0 | 48.2 |
| M | STANDOVER | 28.5 | 28.4 | 28.3 | 28.3 |
| N | AXLE TO CROWN | 21.4 | 21.4 | 21.4 | 21.4 |
| O | OFFSET | 1.7 | 1.7 | 1.7 | 1.7 |
| P | VERTICAL FORK TRAVEL | 4.7 | 4.7 | 4.7 | 4.7 |
