Ripley is good AF at pretty much everything.
Perfect for both seasoned shredders and stoked newcomers, the newest AF version packs the same fast, playful feel the Ripley is known for — into a tough aluminum package that’s ready for anything.
With 130mm of rear travel and 140mm up front, it climbs efficiently and descends way above its travel class. The confident progressive geometry gives it quick and responsive handling on tight trails while keeping things stable when the speed picks up. Designed for riders who value agility, capability, and all-around fun, the Ripley AF shares all the features of its carbon counterpart: dw-link suspension, 29” wheels front and rear, with flip chips to run a 27.5” rear wheel (if you’re into mullets), and in-frame storage with two included Ibis bags — for all your snacks and tools.
| Deore | 90 | Frame | |
| Fork | RockShox Pike, 15QRx110, 140mm | RockShox Pike, 15QRx110, 140mm | |
| Shock | RockShox Deluxe Select 210mm x 52.5mm | RockShox Deluxe Select 210mm x 52.5mm | RockShox Deluxe Select 210mm x 52.5mm |
| Wheels | Ibis 933 Aluminum Rims, Blackbird Hubs | Ibis 933 Aluminum Rims, Blackbird Hubs | |
| Front Tire | Maxxis DHR2, 29" x 2.4", Exo, TR - OR - Maxxis Forekaster, 29" x 2.4", Exo, TR | Maxxis DHR2, 29" x 2.4", Exo, TR - OR - Maxxis Forekaster, 29" x 2.4", Exo, TR | |
| Rear Tire | Maxxis Rekon, 29" x 2.4", Exo, TR | Maxxis Rekon, 29" x 2.4", Exo, TR | |
| Brakes | SRAM G2 4P | SRAM G2 4P | |
| Rotors (F/R) | SRAM Centerline 6-Bolt 180F/180R | SRAM Centerline 6-Bolt 180F/180R | |
| Crankset | Shimano Deore M6120 24mm spindle | SRAM Eagle 90 Transmission DUB 30t Alloy Ring | |
| Bottom Bracket | Shimano MT501 | SRAM DUB BSA | |
| Rear Derailleur | Shimano Deore M6100 SGS | SRAM Eagle 90 Transmission | |
| Shifter | Shimano Deore M6100 Bland Clamp | SRAM Eagle 90 Transmission | |
| Cassette | Shimano Deore, M6100, 10-51T | SRAM XS 1275 Transmission, T-Type, 10-52T | |
| Chain | KMC X12 | SRAM GX Eagle Transmission, T-Type | |
| Headset | Cane Creek 50: ZS44/ZS56 | Cane Creek 50: ZS44/ZS56 | |
| Grips | Lizard Skins Strata Single Clamp | Lizard Skins Strata Single Clamp | |
| Handlebar | Ibis Aluminum, 780mm | Ibis Aluminum, 780mm | |
| Stem | Ibis 31.8mm | Ibis 31.8mm | |
| Seatpost | KS Vantage Dropper, 34.9mm | KS Vantage Dropper, 34.9mm | |
| Saddle | WTB Silverado Fusion CrMo 142 | WTB Silverado Fusion CrMo 142 |
Ibis ultra low standovers give you the ability to size your frame based on horizontal fit without worrying about vertical clearances.
64.9°Head Tube Angle I 76.9–77.9°Seat Tube Angle I 436–442mmChainstays
| Nominal Size | SM | MD | XM | LG | XL | |
|---|---|---|---|---|---|---|
| Seat Tube | A | 395 | 400 | 415 | 457 | 477 |
| Top Tube | B | 577 | 604 | 629 | 654 | 684 |
| Head Tube | C | 85 | 95 | 110 | 125 | 140 |
| Chainstay 29" | D | 436 | 436 | 437 | 440 | 442 |
| Seat Tube Angle | E | 77.4° | 76.9° | 76.9° | 77.4° | 77.9° |
| Saddle Height for Seat Tube Angle | F | 650 | 700 | 745 | 790 | 830 |
| Head Tube Angle | G | 64.9° | 64.9° | 64.9° | 64.9° | 64.9° |
| Wheelbase | H | 1187 | 1211 | 1241 | 1279 | 1321 |
| Stack | I | 613 | 619 | 629 | 640 | 650 |
| Reach | J | 440 | 460 | 483 | 511 | 545 |
| BB Height* | 326 | 329 | 332 | 335 | 338 | |
| BB Drop | K | 48 | 45 | 42 | 39 | 36 |
| Standover | L | 680 | 721 | 744 | 759 | 772 |
| Recommended Seatpost Drop | 140 | 170 | 185 | 213 | 213 | |
| Crank Length | 165 | 165 | 170 | 170 | 170 | |
| Tire Size | 2.35-2.5" | 2.35-2.5" | 2.35-2.5" | 2.35-2.5" | 2.35-2.5" | |
| Water Bottle Size | 1 x 26oz | 1 x 26oz | 1 x 26oz | 1 x 26oz | 1 x 26oz |
| SM | 152 - 168CM |
| MD | 165 - 175CM |
| XM | 173 - 183CM |
| LG | 180 - 191CM |
| XL | 188 - 201CM |
