For the steepest. The angriest. And the most vengeful. Wherever you're going, it already has you covered. At home outside the tape, beyond the norm. Taken on the trails nobody talks about. Trusted on the lines where mistakes can't happen. Comfortable with all the chaos. Pleased when you're puckered.
Fork - Fox Factory 38/170mm
Shock - Fox Factory Dhx2 2 Pos Lever
Wheelset - Dt E1900
Rear - Der Sram Gx Eagle
Shift - Sram Gx Eagle
Crank - Sram Gx Eagle 30t 170mm
Bb - Sram Dub Bb92
Cassette - Sram Gx Eagle 1275 10-52
Chain - Sram Gx Eagle
Brakes - Sram Code R
Rotor - Sram Centerline 200/200
Post - Fox Transfer Performance
Tire (F) - Maxxis Assegai 2.5 Exo+
Tire (R) - Maxxis Minion Dhr Ii 2.4 Exo+
Headset - Cane Creek 40 Integrated
Bar - Race Face Aeffect R 35x780mm
Stem - Race Face Ride 35x50mm
Grips - Odi Elite Pro
Saddle - Silverado Custom
Bash - Guard Oneup Bash Guide
| SM | MD | LG | XL | ||
| A | SEAT TUBE LENGTH | 380 | 410 | 450 | 495 |
| B | TOP TUBE LENGTH [EFFECTIVE] | 567 | 598.5 | 621.5 | 649.4 |
| C | HEAD TUBE ANGLE | 63.5° | 63.5° | 63.5° | 63.5° |
| D | SEAT TUBE ANGLE [EFFECTIVE] | 77° | 77° | 77° | 76.9° |
| E | CHAINSTAY LENGTH | 433 | 433 | 433 | 433 |
| F | WHEELBASE | 1197.7 | 1230.2 | 1255.2 | 1285.2 |
| G | BB HEIGHT [ESTIMATED] | 344.9 | 344.9 | 344.9 | 344.9 |
| H | STANDOVER | 710.4 | 716.3 | 723.4 | 746.7 |
| I | HEAD TUBE LENGTH | 104.8 | 110.4 | 121.6 | 132.8 |
| J | FORK [AXLE-TO-CROWN] | 569.1 | 569.1 | 569.1 | 569.1 |
| K | FORK [OFFSET] | 37.5 | 37.5 | 37.5 | 37.5 |
| L | STACK | 594.9 | 599.9 | 609.9 | 619.9 |
| M | REACH | 430.1 | 460.1 | 480.1 | 505.1 |
| N | FRONT CENTER | 764.7 | 797.2 | 822.2 | 852.2 |
